EasyStand Evolv – Large

PNG50010 Pow’r Up Lift
Brings the user to the standing position with the touch of a button. Includes light touch controller, rechargeable battery and charger, Linak® actuator and an emergency release.

PNG50328 Adjustable/Removable Actuator Handle
Removable actuator handle adjusts the distance of reach to actuator handle to meet user’s needs. Not available with Pow’r Up Lift.

PNG50044 Quad Grip Handle Extension
Attaches to the actuator handle for users with limited dexterity. Adjusts for various hand sizes. Not available with Pow’r Up Lift. Hydraulic actuator required.

PNG50070 T-Style Handle Extension
Attaches to the actuator handle for users with limited range of motion. Makes the first few pumps easier and descending more accessible. Adds additional 7” (18cm) in each direction. Not available with Pow’r Up Lift. Hydraulic actuator required.

PNG50025 Mobile
Self propel the stander. Features flip-away knee pad and push rims, drive wheel locks and enclosed chain drive mechanism. Not available with independent knee pads.

PNG50314 Front Swivel Casters
Locking casters allow for easier steering and movement of stander. Replaces front wheels. Extends footprint to 28”x36” (71x91cm). Not available with Mobile option.

PNG50483 Front Swivel Casters for Swing-Away Front
Locking casters allow for easier steering and movement of stander. Replaces front wheels. Extends footprint to 28”x36” (71x91cm). Not available with Mobile option.

PNG50417 Swing-Away Front
Allows the tray and knee pads to swing away with minimal lifting, providing more room for assisted transfers. Includes black molded tray. Not available on XT or Mobile.

PNG50428 Swing-Away Front for Shadow Tray
Allows the tray and knee pads to swing away with minimal lifting, providing more room for assisted transfers. Includes black molded tray. Not available on XT or Mobile.

PNG50471 Shadow Tray 7”
7″ seat to tray height. Depth range is 3.5”-15” (9-38cm). Includes large, adjustable contoured chest pad. Back option required. Not available with Mobile.

PNG50474 Deep Shadow Tray 7”
7″ seat to tray height. Deeper tray/chest pad adjustment. Depth range is 7.5”-19” (19-48cm). Includes large, adjustable contoured chest pad. Back option required. Not available with Mobile.

PNG50130 Shadow Tray 10”
10″ seat to tray height. Depth range is 3.5”-15” (9-38cm). Includes large, adjustable contoured chest pad. Back option required. Not available with Mobile.

PNG50334 Deep Shadow Tray 10”
10″ seat to tray height. Deeper tray/chest pad adjustment. Depth range is 7.5”-19” (19-48cm). Includes large, adjustable contoured chest pad. Back option required. Not available with Mobile.

PNG50026 Shadow Tray 12”
12″ seat to tray height. Depth range is 3.5”-15” (9-38cm). Includes large, adjustable contoured chest pad. Back option required. Not available with Mobile.

PNG50332 Deep Shadow Tray 12″
12″ seat to tray height. Deeper tray/chest pad adjustment. Depth range is 7.5”-19” (19-48cm). Includes large, adjustable contoured chest pad. Back option required. Not available with Mobile.

PNG50456 Clear Tray for Swing Away
Clear trays designed exclusively for the swing-away front. Tray size is 21”x24” (53x61cm).

PNG50458 Oversized Clear Tray for Swing-Away
Clear trays designed exclusively for the swing-away front. Tray size is 29”x22” (74×56 cm).

PNG50490 Black Molded Angle Adjustable Tray for Swing-Away
Adjusts from 0-35° to provide forearm support and angle activities closer to the user. Designed exclusively for the swing-away front.

PNG50489 Clear Angle Adjustable Tray for Swing-Away
Adjusts from 0-35° to provide forearm support and angle activities closer to the user. Designed exclusively for the swing-away front.

PNG50491 Oversized Angle Adjustable Tray for Swing-Away
Adjusts from 0-35° to provide forearm support and angle activities closer to the user. Designed exclusively for the swing-away front.

PNG50248 Clear Tray Top
Acrylic, replaces standard black molded tray. Tray size is 21”x24” (53x61cm). Not available with Mobile.

PNG50194 Oversized Clear Tray
Large acrylic tray allows more room for reading and functional activities. Tray size is 29”x22” (74x56cm). Not available with shadow tray or mobile

PNG50368 Black Molded Angle Adjustable Tray
Adjusts from 0-35° to provide forearm support and angle activities closer to the user. Tray size is 21”x24” (53x61cm). Not available with shadow tray.

PNG50366 Clear Angle Adjustable Tray
Adjusts from 0-35° to provide forearm support and angle activities closer to the user. Tray size is 21”x24” (53x61cm). Not available with shadow tray.

PNG50295 No-Tray Chest Pad
Provides anterior support to trunk while allowing closer access to cabinets and other hard to reach areas. Works great with the Mobile option. Not available with the swing-away front or shadow tray.

PNG50327 Clear Angle Adjustable Tray for Mobile
Adjusts from 0-35° to provide forearm support and angle activities closer to the user. Tray size is 21”x24” (53x61cm). Not available with shadow tray.

PNG50042 Hand Grips
Provides additional arm and hand support and alignment. Easily movable for precise arm positioning. Attaches with suction cups. Clear tray required.

PNG30000 Large Contoured Chest Pad
Attaches to tray or no-tray bracket to provide anterior support. Replaces standard chest pad. Oval pad is 9.5”Hx15”W (24x38cm). Not available with elbow pad.

PNG50066 Flat Back 13”H
Top of back is 15” (38cm) from seat.

PNG50067 Flat Back 19”H
Top of back is 19” (48cm) from seat.

PNG50062 Contoured Back 13”H
Top of back is 15” (38cm) from seat.

PNG50068 Contoured Back 19”H
Top of back is 19” (48cm) from seat.

PNG50171 Removable Flat Back 13”H
Top of back is 15” (38cm) from seat. Removable back releases with two knobs and provides rear access for patient lift transfers.

PNG50173 Removable Flat Back 19”H
Top of back is 19” (48cm) from seat. Removable back releases with two knobs and provides rear access for patient lift transfers.

PNG50172 Removable Contoured Back 13”H
Top of back is 15” (38cm) from seat. Removable back detaches with two knobs and provides rear access for patient lift transfers.

PNG50174 Removable Contoured Back 19”H
Top of back is 19” (48cm) from seat. Removable back detaches with two knobs and provides rear access for patient lift transfers.

PNG30029 Velcro Positioning Belt
2” (5cm) wide positioning belt has a D-ring Velcro® closure, provides hip stability for user. Fits hip circumference of 26”-55” (66-140cm). Back required.

PNG30306 Velcro Positioning Belt
2” (5cm) wide positioning belt has a D-ring Velcro® closure, provides hip stability for user. Fits hip circumference of 38”-67”. Back required.

PNG30028 Positioning Belt with Airline Style Buckle
2” (5cm) wide positioning belt provides hip stability with the security of an airline style buckle. Fits hip circumference of 26”-55” (66-140cm). Back required.

PNG50192 Chest Strap – 5″Wx19″L
Velcro® and D-ring adjustment. Chest strap pad is 5”Wx19”L (13x48cm). Fits users with chest measurement ranging from 30”-46” (76-117cm). Back required.

PNG50193 Chest Strap – 5″Wx24″L
Velcro® and D-ring adjustment. Chest strap pad is 5″Wx24″L (13x61cm). Fits users with chest measurements ranging from 34”-54” (86-137cm). Back required.

P600002 Back Angle Adjustment Wheel
Provides quick adjustment of the back angle for multi-user environments. Replaces standard 5 point knob. Back required.

PNG50034 Accessories Mounting Bracket
Required for attaching the chest vest, lateral supports, high mount chest vest bracket, head supports and push handles. Back required.

PNG30170 X-Style Chest Vest – 11″Lx9.5″W
Neoprene®. Size is 11”Lx9.5”W (28x24cm). Back required.

PNG30056 X-Style Chest Vest – 14.5″Lx10.5″W
Neoprene®. Size is 14”Lx10.5”W (37x27cm). Back required.

PNG30171 Y-Style Chest Vest – 17.5″Lx11.5″W
Neoprene®. Size is 17.5″Lx11.5″W (44x29cm). Back required.

PNG30021 Y-Style Chest Vest – 20.5″Lx12.5″W
Neoprene®. Size is 20.5″Lx12.5″W (52x32cm). Back required.

PNG11212 High Mount Chest Vest Bracket
Moves mounting points for chest vest higher to secure shoulders in position. Chest vest not included. Back and accessories mounting bracket required.

PNG50224 Lateral Supports – 8″-16.5” W
Multiple adjustments, removable for transferring. Depth range is 3” (8cm). Height range is 4”-12″ (10-30cm). Pad size is 4”x6” (10x15cm). Back and accessories mounting bracket required.

PNG50176 Lateral Supports – 11″-19.5” W
Multiple adjustments, removable for transferring. Depth range is 3” (8cm). Height range is 4”-12″ (10-30cm). Pad size is 4”x6” (10x15cm). Back and accessories mounting bracket required.

PNG50240 Head Support – 21″-30″ Range
Height range from seat with a 15″ back is 21″-30″ (53-76cm) and with a 19″ tall back it is 23″-32″ (58-81cm).
Back and accessories mounting bracket required.

PNG50037 Head Support – 25″-34″ Range
Height range from seat with a 15″ back is 23″-32″ (58-81cm) and with a 19″ tall back it is 25″-34″ (64-86cm).
Back and accessories mounting bracket required.

PNG50040 Push Handles
Makes pushing the stander easier for the caregiver. Back required..
